PointHTTPConvert Your .http Files Into A Stunning Interactive Playground
PointHTTP automatically generates an elegant, in-browser REST client and documentation portal for your Express, NestJS and other nodejs frameworks backend with zero extra setup.
⚡ Interactive Experience Sandbox
Experience PointHTTP in action! Try selecting endpoints on the left, editing environment variables inside the grid, and clicking "Send Request" to watch responses render in our collapsible JSON tree viewer.
PointHTTP Playground (.http REST Client)
Consolidated, fully interactive API documentation. You can test and execute requests directly inside your browser!
# 3. GET USER PROFILE
# =========================================================================
API Response
Drawer Awaiting Request
Click a "▷ Send Request" link inside the HTTP cards to open results.
📦 Built for Modern API Workflows
A self-contained development tool that empowers your testing suite and document pipelines.
Modular Folder Scanning
PointHTTP recursively crawls your specified directory, scans modular .http documents, and automatically mounts them into a structured, clickable tree layout.
In-Browser Request Engine
Requests are executed using your browser's native fetch API. Test local environment APIs, staging networks, and cookie-authenticated sessions directly.
Dynamic Variables Grid
Features a live-syncing key/value grid editor allowing developers to update dynamic credentials (e.g. baseUrl or JWTs) which auto-inject into active paths.
Collapsible JSON Tree
Ditch huge, unreadable JSON blobs. Inspect nested structures with an interactive collapsible tree supporting custom styling for strings, booleans, and nulls.
Local Storage Snapshots
Save response states, request variables, and history directly inside the user's browser, keeping their playground workspace cached across sessions.
100% Insulated SSRF Protection
Since all network calls dispatch from the user's browser client and not the hosting Node server, your internal servers are perfectly isolated from request forgery exploits.
📄 How to Write .http Files
PointHTTP parses standard RFC 2616 REST Client files. Organize your workspace using simple .http sheets to define variables and endpoints.
💡 Syntax Convention Reference
- Variables definition: Declare key-value request variables using
@variableName = value. PointHTTP preloads and resolves these in request cards. - Request blocks: Specify the request verb (
GET,POST, etc.) followed by the target URL. - Request headers: Write standard key-value headers directly below the request line (e.g.
Content-Type: application/json). - Payload body: Add a single blank line after your headers, then write your raw text or JSON request payload.
- Request separation: Separate multiple endpoints in a single file using
###(three hashtags) as a clean block delimiter.
# 1. Declare workspace local variables
@baseUrl = http://localhost:5000/api/v1
@token = ph_token_live_7x89yZ12
# 2. First request block
# @name authenticateAdmin
POST {{baseUrl}}/auth/login
Content-Type: application/json
{
"email": "peter.paul@yopmail.com",
"password": "Password1!"
}
###
# 3. Second separated request block
# @name getSystemModules
GET {{baseUrl}}/modules
Authorization: Bearer {{token}}⚡ Integration in 2 Minutes
Mount PointHTTP as a standard Express-compatible middleware and expose it safely in your Node environments.
playground()import express from 'express';
import { playground } from 'pointhttp';
const app = express();
// 1. Zero-config: Scans default src/modules
app.use('/docs/http', playground());
app.listen(3000, () => {
console.log('⚡ Running at http://localhost:3000/docs/http');
});playground(options)import express from 'express';
import { playground } from 'pointhttp';
import path from 'path';
const app = express();
// 2. Custom configuration & preloaded variables
app.use(
'/docs/http',
playground({
modulesDir: path.join(process.cwd(), 'src/endpoints'),
title: 'Custom API Docs Portal',
logoText: 'C1',
logoTitle: 'CustomDocs',
// Preload custom authorization and default variables
envVariables: {
baseUrl: 'https://api.production.com/v1',
authToken: 'ph_token_live_7x89yZ1239840abcde',
},
// Allowed environments for security verification
enabledEnvironments: ['development', 'test', 'staging'],
})
);
app.listen(3000);💡 Configuration Parameters Explained
Calling playground() with no parameters automatically scans your workspace directory for .http files. To custom-brand your documentation or preset environment variables, pass a configuration object:
🛡️ Enterprise Grade Security Gateways
Insulate your sandbox and staging playgrounds from unauthorized traffic. Define granular access controllers.
⚡ Alphanumeric Secret Code
Perfect for lightweight authorization. Team members gain access by visiting a URL formatted with a query parameter code, e.g., https://yourdomain.com/docs/http?code=SECRET_ACCESS_CODE. The middleware intercepts and evaluates this on the server.
playground({
modulesDir: path.join(process.cwd(), 'src/modules'),
customAuth: (req, res) => {
// Alphanumeric URL query parameter code verification
const accessCode = req.query?.code;
const SECRET_ACCESS_CODE = process.env.PLAYGROUND_ACCESS_CODE || 'A89F2K8Z';
return accessCode === SECRET_ACCESS_CODE;
}
})
# 2. ADMIN AUTHENTICATION
# =========================================================================
